HDC1080 Temperature+Humidity Sensor
The HDC1080 Temperature+Humidity sensor allows you to use your HDC1080
(datasheet
,
Adafruit) sensors with
ESPHome. The I²C Bus is
required to be set up in your configuration for this sensor to work.
# Example configuration entry
sensor:
- platform: hdc1080
temperature:
name: "Living Room Temperature"
humidity:
name: "Living Room Humidity"
update_interval: 60sConfiguration variables:
temperature (Required): The information for the temperature sensor.
- All options from Sensor.
humidity (Required): The information for the humidity sensor
- All options from Sensor.
update_interval (Optional, Time): The interval to check the sensor. Defaults to
60s.
Currently, the platform doesn’t support activating the built-in heater, as it seems to only be rarely of use. If you need it, please open an issue.
Notes
This library also appears to the compatible with the DFRobot CHT8305 I2C Temperature and Humidity Sensor) on address 0x40.
# Example configuration entry
sensor:
- platform: hdc1080
temperature:
name: "Outside Temperature"
humidity:
name: "Outside Humidity"
address: 0x40
update_interval: 60s
